It works with any standard touchscreen display, and runs on standard Windows PCs. Slot functions can be set in user profiles and recalled when users log in.įor those who prefer to use an off-console touchscreen monitor instead of the Virtual Extension module, the Diamond Desktop App comes with every diamond console. When the diamond Combo Module is used, 2 user-selectable “slots” are available.
When the full-width diamond Central Control Module is used with the Virtual Extension Module, 4 “slots“ are provided on-screen that you can fill with program output meters, loudness metering, user shortcut keys, NTP-synchronized clock, event timers – even video feeds. An interactive parameter control page is shown when a channel’s Access mode is activated just touch the screen to trim voice processing and other DSP parameters, fine-tune delay times, recall console snapshots, load audio sources and adjust source and monitor gain. Each fader strip is augmented with a realtime bargraph display and tallies that illuminate when DSP processing is active, plus bus assignment indicators and an info-strip with source name and details. Virtual Extension comes with a pre-configured collection of ready to run control screens. So much power - delivered with all the style and finesse that broadcasters expect from Lawo broadcast consoles. Touch-sensitive faders and rotary controls with vibrant, full-color displays. Virtual Extensions that provide immediate information for every function. Scalable from as few as 2 to as many as 60 physical faders.
Completely modular configurable to your most specific wishes. A seamless synergy of physical and virtual operation, with intelligent context-sensitive controls that fall naturally to hand.ĭiamond is truly cutting edge.
Our design philosophy is simple: give broadcast professionals a mixing console so intuitive, so easy to use, that using it feels as natural as breathing. This is why Lawo created the diamond broadcast console for radio and TV applications. And to achieve the highest levels of productivity, your tools must operate as extensions of yourself. The more demanding the job, the higher quality the tools must be. DSP Builder includes both a hardware-optimized Standard Blockset and Advanced Blockset for use within the Simulink Library Browser.ĭSP Builder Advanced Blockset is a constraint-driven, behavioral Model-Based Design environment, offering significant advantages in terms of design management and productivity for designing complex signal processing systems.Every job requires the proper tools. DSP Builder integrates Simulink ® with Intel Quartus Prime design software, creating a workflow for configuring Intel FPGAs. DSP Builder for Intel ® FPGAs is a high-level design tool that allows engineers to accomplish high performance DSP systems using Model-Based Design.
